Scribe-Master DG/JIG Draining Groove Jig

Scribe-Master DG/JIG Draining Groove Jig

The Scribe-Master DG/JIG Draining Groove Jig is the ultimate tool for routing draining grooves in solid timber for Belfast-type and under-mount sinks. Crafted from 12mm thick CNC machined phenolic, this durable and precise jig ensures efficient and accurate results, making it a must-have for any woodworking professional.

Scribe-Master is the UK’s number one name in woodworking jigs, with over eight years of experience manufacturing high-quality jigs for major companies in the industry.

Features:

• Perfect for routing draining grooves in solid timber for Belfast type and under-mount sinks
• Anti-Bow Technology: Prevents ‘dishing’ in the worktop, ensuring efficient water drainage and a flawless finish
• Manufactured from exterior grade high-density laminate, providing exceptional strength, precision, and durability
• Includes 3 jig support runners that maximise router support and incorporate a built-in 0.5° fall, eliminating the need for spacers and speeding up the setup process
• Features 8 drainer grooves at a 50 mm pitch and 455 mm length, allowing for consistent and precise draining groove placement

Specification:

• Fall: 0.5 degree
• Groove pitch: 50.0 mm
• Groove length: 455 mm
• Slat width: 19.8 mm
• Length: 600 mm
• Height: 585 mm
• Width: 12 mm 22
• Weight: 4.3kg
